Techtop BK3-CI-TF-444T-6-RR-G-100 TEFC 100 HP 1200 444T Oil Pump Motor
Techtop BK3-CI-TF-444T-6-RR-G-100 TEFC 100 HP 1200 444T Oil Pump Motor
Regular price
$8,549.60
Regular price
Sale price
$8,549.60
Shipping calculated at checkout.
Quantity
Couldn't load pickup availability
Techtop Oil Pumper motors are engineered specifically for high inertia starting loads, such as oil pumps and cranes. NEMA Design code 'D' allow for higher 'slip' while boosting starting torque.
Spec Sheets
3D Models
Share
Specifications, Features and Documentation
-
Specs
Model: BK3-CI-TF-444T-6-RR-G-100
Phase: Three-Phase
Power: 100 HP
RPM: 1200
Frame: 444T
Enclosure: TEFC
Voltage: 230/460/796V
FL Amps:
Bearings: Regreasable Roller Bearing
Weight: 1602 lb
Efficiency: Standard Efficiency
Construction: Cast Iron
Application:
- Oil Pump
-
Features
- 5%-8% Slip NEMA Design D
- Double Lip Oil Seals on Both Ends
- Cast Iron Terminal Box with Gasket
- Roller Bearing on 404T and Above
- TEFC Cast Iron Frame
- Corrosion Resistant Hardware
- T-Box Mount Position Convertable F1,F2,F3 up to 326T
- Class F Insulation , Class H Stator
- VPI and Tropicalization on Stator Winding
- One-Way Brass Condensation Drains
- 24 Month Warranty
