Contactor overloads protect electric motors and other heavy loads from various faults, including over-current, overload, phase-loss and phase imbalance. They disengage the contactor when a fault condition is detected.
Contactor Overloads
-
WEG WEG RWM420E-3-A4U250 Electronic Overload Relay 50.0-250 Amp
The Weg RW-E series of electronic overload relays are designed to protect expensive motors from damage due to overloads, phase loss, and current unblances. The Weg electronic relay is up to 87% more energy efficient compared to thermal overload relays, saving on both energy and cabinet ventilation demands. They also have a much larger settable current range as compared to the thermal overloads, thus reducing spare parts inventory. The entire current range from 0.4 to 820 amps is covered by just 4 RW-E products. Specs Direct mounting to WEG CWM112, CWM150, CWM150N, CWM180, CWM250, CWM300, CWM300N, CWM400, CWM500 contactors Current Setting Range: 50.0-250 Amps Number of power poles: 3 Auxiliary Contacts: 1 N.O., 1 N.C, isolated Auto/Manual Reset Button Features Adjustable trip class 10,20 or 30 Wide range settable current overload value Overload, phase-loss and current unbalance protection Red flag trip indication Isolated NO and NC auxiliary contacts Manual/Auto/Remote RESET button Low energy consumption and low power dissipation Direct mounting below Weg contactorsStand-alone mount accessory allows mounting anywhere Selectable Auto or Manual Reset Documentation Weg Electronic Overload Flyer Weg Electronic Overload Catalog Accessories GA317-1D: Overload Connector Links for CWM112/150 contactors GA317-2D: Overload Connector Links for CWM180 contactors GA317-3D: Overload Connector Links for CWM250/300 contactors GA317-10D: Overload Connector Links for CWM400 contactors IBRW317: Phase Barrier for RWM40E Overloads CSW-BHF437: Overload Relay Reset Button with adjustable shaft
$322.91
-
WEG WEG RWM420E-3-R4U250 Electronic Overload Relay 50.0-250 Amp Remote Reset
The Weg RW-E series of electronic overload relays are designed to protect expensive motors from damage due to overloads, phase loss, and current unblances. The Weg electronic relay is up to 87% more energy efficient compared to thermal overload relays, saving on both energy and cabinet ventilation demands. They also have a much larger settable current range as compared to the thermal overloads, thus reducing spare parts inventory. The entire current range from 0.4 to 820 amps is covered by just 4 RW-E products.This model features 2 extra control terminals, A3,A4, for optional remote reset. By applying 24VDC to these terminals, the relay may be reset from an overload condition. Manual reset still available from the blue button on the front. Specs Direct mounting to WEG CWM112, CWM150, CWM150N, CWM180, CWM250, CWM300, CWM300N, CWM400, CWM500 contactors Current Setting Range: 50.0-250 Amps Number of power poles: 3 Auxiliary Contacts: 1 N.O., 1 N.C, isolated Auto/Manual Reset Button, Remote Reset via terminals A3,A4 Features Adjustable trip class 10,20 or 30 Wide range settable current overload value Overload, phase-loss and current unbalance protection Red flag trip indication Isolated NO and NC auxiliary contacts Manual/Auto/Remote RESET button Low energy consumption and low power dissipation Direct mounting below Weg contactorsStand-alone mount accessory allows mounting anywhere Selectable Auto or Manual Reset Documentation Weg Electronic Overload Flyer Weg Electronic Overload Catalog Accessories GA317-1D: Overload Connector Links for CWM112/150 contactors GA317-2D: Overload Connector Links for CWM180 contactors GA317-3D: Overload Connector Links for CWM250/300 contactors GA317-10D: Overload Connector Links for CWM400 contactors IBRW317: Phase Barrier for RWM40E Overloads CSW-BHF437: Overload Relay Reset Button with adjustable shaft
$342.68
-
WEG WEG RWM420E-3-A4U420 Electronic Overload Relay 85.0-420 Amp
The Weg RW-E series of electronic overload relays are designed to protect expensive motors from damage due to overloads, phase loss, and current unblances. The Weg electronic relay is up to 87% more energy efficient compared to thermal overload relays, saving on both energy and cabinet ventilation demands. They also have a much larger settable current range as compared to the thermal overloads, thus reducing spare parts inventory. The entire current range from 0.4 to 820 amps is covered by just 4 RW-E products. Specs Direct mounting to WEG CWM112, CWM150, CWM150N, CWM180, CWM250, CWM300, CWM300N, CWM400, CWM500 contactors Current Setting Range: 85.0-420 Amps Number of power poles: 3 Auxiliary Contacts: 1 N.O., 1 N.C, isolated Auto/Manual Reset Button Features Adjustable trip class 10,20 or 30 Wide range settable current overload value Overload, phase-loss and current unbalance protection Red flag trip indication Isolated NO and NC auxiliary contacts Manual/Auto/Remote RESET button Low energy consumption and low power dissipation Direct mounting below Weg contactorsStand-alone mount accessory allows mounting anywhere Selectable Auto or Manual Reset Documentation Weg Electronic Overload Flyer Weg Electronic Overload Catalog Accessories GA317-1D: Overload Connector Links for CWM112/150 contactors GA317-2D: Overload Connector Links for CWM180 contactors GA317-3D: Overload Connector Links for CWM250/300 contactors GA317-10D: Overload Connector Links for CWM400 contactors IBRW317: Phase Barrier for RWM40E Overloads CSW-BHF437: Overload Relay Reset Button with adjustable shaft
$382.22
-
WEG WEG RWM420E-3-R4U420 Electronic Overload Relay 85.0-420 Amp Remote Reset
The Weg RW-E series of electronic overload relays are designed to protect expensive motors from damage due to overloads, phase loss, and current unblances. The Weg electronic relay is up to 87% more energy efficient compared to thermal overload relays, saving on both energy and cabinet ventilation demands. They also have a much larger settable current range as compared to the thermal overloads, thus reducing spare parts inventory. The entire current range from 0.4 to 820 amps is covered by just 4 RW-E products.This model features 2 extra control terminals, A3,A4, for optional remote reset. By applying 24VDC to these terminals, the relay may be reset from an overload condition. Manual reset still available from the blue button on the front. Specs Direct mounting to WEG CWM112, CWM150, CWM150N, CWM180, CWM250, CWM300, CWM300N, CWM400, CWM500 contactors Current Setting Range: 85.0-420 Amps Number of power poles: 3 Auxiliary Contacts: 1 N.O., 1 N.C, isolated Auto/Manual Reset Button, Remote Reset via terminals A3,A4 Features Adjustable trip class 10,20 or 30 Wide range settable current overload value Overload, phase-loss and current unbalance protection Red flag trip indication Isolated NO and NC auxiliary contacts Manual/Auto/Remote RESET button Low energy consumption and low power dissipation Direct mounting below Weg contactorsStand-alone mount accessory allows mounting anywhere Selectable Auto or Manual Reset Documentation Weg Electronic Overload Flyer Weg Electronic Overload Catalog Accessories GA317-1D: Overload Connector Links for CWM112/150 contactors GA317-2D: Overload Connector Links for CWM180 contactors GA317-3D: Overload Connector Links for CWM250/300 contactors GA317-10D: Overload Connector Links for CWM400 contactors IBRW317: Phase Barrier for RWM40E Overloads CSW-BHF437: Overload Relay Reset Button with adjustable shaft
$408.58
-
Weg WEG RW407-2D3-U840 3 Pole Overload Relay 560-840 Amp
Weg RW series of thermal overload relays are Class 10 overloads designed to protect motors from damage due to overloads, phase loss, and current unbalance. Available in a wide range of current settings. Many accessories are available, including stand-alone mounting brackets, connector links, and more. Specs Direct mounting to WEG CWM800 contactors Current Setting Range: 560-840 Amps Number of power poles: 3 Auxiliary Contacts: 1 N.O., 1 N.C, isolated Features Overload, phase-loss and current unbalance protection Class 10 Trip Characteristics Isolated NO and NC auxiliary contacts Manual/Auto/Remote RESET button Direct mounting below Weg contactors Stand-Alone accessory allows mounting anywhere Selectable Auto or Manual Reset Documentation Weg Thermal Overload Flyer Weg Overload Relay Catalog Accessories CSW-BHF437: Overload Relay Reset Button with adjustable shaft
$454.71
-
WEG WEG RWM840E-3-A4U840 Electronic Overload Relay 170-840 Amp
The Weg RW-E series of electronic overload relays are designed to protect expensive motors from damage due to overloads, phase loss, and current unblances. The Weg electronic relay is up to 87% more energy efficient compared to thermal overload relays, saving on both energy and cabinet ventilation demands. They also have a much larger settable current range as compared to the thermal overloads, thus reducing spare parts inventory. The entire current range from 0.4 to 820 amps is covered by just 4 RW-E products. Specs Direct mounting to WEG CWM150, CWM150N, CWM180, CWM250, CWM300, CWM300N, CWM400, CWM500, CWM630, CWM800 contactors Current Setting Range: 170-840 Amps Number of power poles: 3 Auxiliary Contacts: 1 N.O., 1 N.C, isolated Auto/Manual Reset Button Features Adjustable trip class 10,20 or 30 Wide range settable current overload value Overload, phase-loss and current unbalance protection Red flag trip indication Isolated NO and NC auxiliary contacts Manual/Auto/Remote RESET button Low energy consumption and low power dissipation Direct mounting below Weg contactorsStand-alone mount accessory allows mounting anywhere Selectable Auto or Manual Reset Documentation Weg Electronic Overload Flyer Weg Electronic Overload Catalog Accessories CSW-BHF437: Overload Relay Reset Button with adjustable shaft
$856.70
You have seen 150 out of 150 products
