Cerus MRC-9B-208VAC IEC 3-pole Size 00 Contactor 9 Amp 208VAC Coil
Cerus MRC-9B-208VAC IEC 3-pole Size 00 Contactor 9 Amp 208VAC Coil
Regular price
$28.04
Regular price
Sale price
$28.04
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
The Cerus line of IEC contactors provide a reliable cost-effective way of starting and stopping higher current loads, such as electric motors and large lighting systems. The IEC design allows for an easy snap on/off mounting to an existing DIN rail. Available in a wide variety of amp ratings and control voltage coil ratings. These 3-pole contactors also feature included N.O. and N.C. auxiliary contacts. Optional current protection thermal overload relays are also available.
Download the Franklin Electric Industrial Components Catalog
Specs
| Contact Rating | 9 Amps |
| Rated Insulation Voltage | 1000 V |
| NEMA Size | 00 |
| HP Ratings (single-phase) | 1/2 HP (120VAC), 1.5 HP (240 VAC) |
| HP Ratings (3-phase) | 2 HP (208VAC), 3 HP (240 VAC), 5 HP (480VAC) |
| Coil Voltage | 208 VAC |
| Dimensions (inches) | 1.77 W x 2.89 H x 3.17 D |
| Standards | IEC/EN 60947-1,IEC/EN 60947-4-1,UL 508, K60947 |
| Certifications | UL, CSA, CE, ABS |
Overload Relays
 |
Overload relays will help protect your motor or other load from damage if the motor or other device gets overloaded, or a phase is lost. This device, pictured below, attaches below the contactor and will disengage the contacts should an over-current be detected. Current range is settable from the front dial. See our complete line of Cerus IEC Overload Relays. |
